Specs
Benchmark Prop10x6 for break-in
Bore0.866" (22mm)
Carb TypeO.S. 40K 2-needle rotary
Crankshaft ThreadsUNF5/16 - 24
Crankshaft TypeThreaded
CylindersSingle
Cylinder TypeAdvanced Bi-Metallic Liner
Displacement0.455 cu in (7.45cc)
Engine (Only) Weight13.3 oz (378g) w/o muffler
Power TypeGlow
HP1.65 PS, 1.67 HP @16,000 RPM
Muffler Type2-piece aluminum
Muffler Weight3.81 oz (108 g)
Oil Type & ContentAt least 16% synthetic lubricant
Plug TypeA3
Product Height3.3" (85.2mm) crankcase botton to top of cylinder head
Product Length4.4" (111.7mm) from backplate to end of crankshaft
Product Width2" (50.8mm) including mounting tabs
Prop Range10.5x6 - 12x6-7
Recommended Fuel5%-20% nitromethane
RPM Range2,000 - 17,000
Stroke0.772" (19.6mm)
